15, 2019 To install:. Click the download button and save Hauppauge Capture to your PC (do not select 'Run'). Once Hauppauge Capture is downloaded, run the Hauppauge Capture installation. After installation, you will be asked to reboot your PC. Please reboot. While rebooting your PC, if you have an HD PVR 2 or HD PVR Pro 60, remove the power plug from the back of the HD PVR 2 (or the USB connector on the HD PVR Pro 60) for a few seconds and then plug it back in. Dd-wrt special edition qos.
This resets the devices. Once your PC is rebooted, you will see the Hauppauge Capture icon on your Windows desktop.
No other setup is needed.Hauppauge Capture supports the following products:. HD PVR Pro 60. HD PVR 2 (all models). Colossus 2 and Colossus. HD PVR Rocket. HD PVR 60.
HD PVR model 1212. USB-Live2. ImpactVCBe and ImpactVCB. Note: if you have the Colossus 2, HD PVR 2 model 1512 or the HD PVR 2 GE+, if you have 5.1 channel AC3 audio from HDMI or optical audio, your recordings will have 5.1 channel AC-3 audioPersonal Logo applicationThe HD PVR 2 and Colossus 2 Logo Inserter puts a graphic in your recordings or video streams. It does this automatically, branding your videos and streams with your logo. In the TV industry, an on-screen logo is called a 'digital onscreen graphic' or 'TV bug', and you can often see this in the lower right hand corner of news programs on TV. The Hauppauge Personal Logo application uses the Logo Inserter, and is part of the Hauppauge Capture application (it can be found in the Settings tab).
There is also a standalone version which is installed with the HD PVR 2 Installation package.Here is a short test video we made using the logo inserted by the Personal Logo application. Some tips on using the Personal Logo application. The logo must be less than 1200pixels x 550pixels and be a GIF, BMP or PNG format. PNG files are recommended since they can be transparent. When creating a PNG file, create 24-bit transparent logos.
In Hauppauge Capture, click the Settings tab and then click ' Enable Personal Logo'. Then click ' Browse' and find your logo. Once you open the logo, you can position it on the screen by dragging it around with your mouse. Then click the ' Apply' button to add your logo. If you change the record resolution, the HD PVR 2 record application will calculate where to reposition it to keep it in the same spot. You can adjust the transparency by using the Alpha slide bar.
All the way to the right makes the logo fully opaque, while moving it to the middle makes the logo semi-transparent. The settings are 'sticky'. Once set, they will be applied to all future recordings (unless you re-run the Personal logo program and make changes). HD PVR 2 and Colossus 2 Windows DriversTo install this Windows driver update:. Click on the download link.
You will be given an option to Run or Save the file. Click Save to save the file in your Download folder.
Run this file. It will install the Windows driver. When finished running the update, you will be ask to restart your PC. Restart your PC. While the PC is restarting, power cycle your HD PVR 2 to load the new firmware.
To power cycle the HD PVR 2, remove power from the unit for a few seconds and then plug it back in. When your PC has rebooted, you should see the Hauppauge Capture icon on your Windows desktop. Double click on the Hauppauge Capture icon. Note: You will not see video on your TV set until you run Hauppauge Capture once. If your cables are connected, you should now be able to see your game console on your TV set and record and stream your gameplay.HD PVR 2 Windows driver version 37119. This version has a fix for an Error code 52 found with some versions of Windows.
To install the driver updates:. Download this file.
Click the file to install. When the Windows driver has been installed, you will see a message Drivers installation status: Success. When finished running the update, you will be ask to restart your PC. Restart your PC. While the PC is restarting, power cycle your HD PVR 2 to load the new firmware. To power cycle the HD PVR 2, remove power from the unit for a few seconds and then plug it back in.
HD PVR 2 Connection DiagramsHD PVR 2 has “no delay passthrough” so you can play your video game while recording. To use the no delay pass through, simply connect HD PVR 2 between your game console and your HD TV set. HDMI output is provided to make it easy to connect to your TV monitor.For recording HD TV programs from a cable or satellite TV box, connect either Component video from your cable or satellite box to the AV Input on the back of the HD PVR 2. On some TV channels, you can also record from the HDMI connector on your set top box (not all channels can be recorded using HDMI, but Component video works with all TV channels).
Use the included WinTV application to schedule recordings of your TV programs. To install this version of StreamEez:. Click on the download link. You will be given an option to Run or Save the file. Click Save to save the file in your Download folder. Run this file.
It will install the StreamEez-Pro application plus the Windows driver. When finished running the update, you will be ask to restart your PC. StreamEez Software Setup Step 2.
Then choose your Stream Service, either Twitch or YouTube. ( You must have an account setup with the stream service you wish to use). In Channel, select Login. Enter your Login and Password. You will see a message 'Gathering credentials' as we check your user name and password. Once your user name and password are confirmed, you will see the URL of your stream in the box 'Copy stream link'. If you click on the words 'Copy stream link', the URL will be copied to the clip board.Step 3.
Leave the Network Connection as the defaultTo start streaming. To start streaming, click the red dot next to 'Off Air.' The indicator should be changed to 'On Air' and you will now be streaming live over the Internet!. Once you are On Air, you cannot change any settings. You need to stop streaming by clicking the green dot next to On Air to stop the stream. How to turn off HDCP on your PS4 Are you unable to record video, getting no video (but you might get choppy audio) in your recordings or a black screen in Hauppauge Capture? Does the Input resolution indicator in Hauppauge Capture switch between '1920x1080p 60fps' and 'Waiting for HDMI video signal'?
If so, you should turn off HDCP copy protection on your PS4Hauppauge game recorders cannot record HDMI video which has HDCP copy protection. Video with HDCP copy protection can come from an Xbox One or a PS4, or a cable TV or satellite box. Note: if you have a cable TV or satellite box, you should use Component video and not HDMI.
HDMI out on cable/sat boxes often has HDCP copy protection.If you have a PS4, you need to disable HDCP. Here is how to do this:. First, connect your PS4 directly to your gaming monitor (since you will not be able to see the PS4 on your computer screen if there is HDCP copy protection on the PS4). Next, go to Settings: from the main user interface, push up on the DualShock 4 to reach the top-level of the system’s menu, and select the toolbox labelled ‘Settings’.
Enter the System submenu: When the long list of options appears, scroll down to the icon named ‘System’ and select it. Turn off HDCP encryption: You’ll find another long list in Settings.
Scroll down to ‘Enable HDCP’ and ensure that the box to the right of the label is not checked. It will be enabled by default, so simply click on it to disable the HDCP copy protection. If you have any applications open, the system will ask you to close them, so make sure that you’ve saved your game before completing this last step. Now you can reconnect your PS4 back to the Hauppauge game recorder, and the HDMI out of the Hauppauge game recorder to your TV monitor. You should be able to see your game on your computer screen and TV monitor. Using HD PVR 2 to record PC game play or your PC screen using HDMIHow To: Setup the HD PVR 2 with a Gaming PC via HDMINote: HD PVR 2 can accept video from a PC in the following formats ONLY: 1920 x 1080 at 60Hz max, 1280 x 720 at 60 Hz max and 720 x 480 at 60 Hz max.
If you are running in any other video mode, you will see either a black screen or distorted video. Check your video mode!Note: if you do not have audio in your recordings, please refer to Steps 4 and 4a. When using HDMI Output on a PC, audio can go to either the HDMI connector or the Speaker output. If you do not have audio in your recordings, then audio is going from the wrong place on your PC. Step 1 - Install the HD PVR 2 on your PCConnect the HD PVR 2 to your PC (the PC where you will be recording) using the supplied USB cable. Connect the power to the HD PVR 2.Install Hauppauge Capture from this Support page in the Capture tab.When you are finished with the installation, you will need to reboot your PC. While your PC is rebooting, power cycle the HD PVR 2 by removing the power connector for a few seconds.After you reboot, run Hauppauge Capture by double clicking on the icon on your Windows desktop.At this point you might not see video in the Capture preview window.
This is normal. Step 2 - Configure your Gaming PC's video modeNote: HD PVR's can accept video from a PC in the following formats ONLY:. 1920 x 1080 at 60Hz max (1080p60). 1280 x 720 at 60 Hz max (720p). 720 x 480 at 60 Hz max (480p)If you are running in any other video mode, you will see either a black screen or distorted video. Check your video mode!Screen resolution menu on your Windows PC.
The Resolution must be set to either 1920X1080 or 1280X720.On the computer where you will be playing your video games (we'll call this the Gaming PC), connect an HDMI cable from your graphics card HDMI port to the HDMI in on the HD PVR.Note: your Gaming PC screen may go black for several seconds and then you will be back at the Windows desktop.Under Display you should see your HD PVR model in the drop down menu. Example: HD PVR 2.SelectUnder Resolution, set to either 1920X1080 or 1280X720.Under Multiple displays, set to Duplicate these displays.Click. Set Refresh Rate to 60p Hz Set Scaling to Maintain Display Scaling. Step 3 - Connect the HDMI cable from your Gaming PC to the HD PVR's HDMI In connectorIf you have a gaming laptop, simply plug an HDMI cable from your laptops' HDMI out port into the HDMI In on the HD PVR. You should see your PC screen on the video monitor.If you do not, click the Windows button on your keyboard and at the same time the P key. Then select Duplicate. If you have set your PC's video mode correctly (step 2 above), you should see your PC screen on the video monitor.If you have a desktop PC, then remove the HDMI cable which is plugged into the monitor and plug it into the HDMI In port on the HD PVR.
Then take an HDMI cable and plug one end into the HDMI Out port on the HD PVR and the other end into an HDMI port on your monitor. If you have set your PC's video mode correctly (step 2 above), and you have selected the correct HDMI source on your TV set, you should see your PC screen on the video monitor. Step 4 - Configure the audio on your Gaming PC if sound comes through your HDMI cable Recording from a PC?
Here's how to set the audio.Playback soundIf you are using the HDMI pass through on the HD PVR (if you are not using HDMI pass-through skip to step 4a), on your Gaming PC right click on the Speaker icon on the taskbar and select Playback device.In Playback devices find your HDMI connection to the HD PVR (it should say HD-PVR2, HD PVR Rocket or sometimes Digital audio (HDMI)). Right click and select Set as default device.Step 4a - Adapters needed to split the audio from your gaming PC Step 4a - Configuring audio if you are using speakers connected directly to your Gaming PCIf you are listening to sound from your Gaming PC through speakers and not on your video monitor, to hear audio without any audio delay you will need to split the audio coming from your Gaming PC. To do this, you will need two adapters: an 1/8th inch stereo Y adapter, a 1/8th inch stereo to RCA male adapter.and an Audio cable set. Yes, a PC or laptop is required to use HD PVR 2.
The PC is used to both run the HD PVR 2 application plus is the place where HD PVR 2 recordings are stored. HD PVR 2 does not have any internal disk storage. HD PVR 2 connects to a PC or laptop computer through a USB 2.0 port. The HD PVR 2 recordings are stored on the PC's disk drive.If you want to record your HD videos without a PC, you should use the.If you have a Mac, there is an application from HDPVRCapture which can be used. Go to for more information. I use the HD PVR 2 Gaming Edition. I was wondering how I can record my commentary with game audio?
With the Hauppauge Capture application, you can plug your microphone into the 'mic input' on your PC. Hauppauge Capture will mix your game play audio with microphone audio. With Hauppauge Capture, there are seperate volume adjustments for game play and microphone audio. You can also add PC sound (music or Skype audio) to mix together PC audio with game audio and your game commentary.In some cases, in order to have third party chat in your recordings and streams, you might need the. What types of video sources can I record? The HD PVR 2 can record from HDMI (without HDCP), Component video and composite video.
Video input resolutions can range from standard definition 720x480 up to 1080p60.Common examples are:. video cameras with HDMI out. game consoles such as the Xbox One, PS4, PS3, Xbox 360. PC Graphics cards (from the HDMI port on the graphics card) so you can record your PC screen.
cable or satellite set top box can be recorded from Component video and composite video. HDMI is often blocked with HDCP copy protection on cable and satellite boxes, so you should use Component (red/green/blue connectors on the back of your cable/satellite box) or composite video (the yellow connector on the back of your cable/satellite box) for best results. Some people have reported they can record HDMI from a cable/satellite box, but many boxes block the HDMI port with HDCP copy protection.How to turn off HDCP on a PS4. On the PS4, go to Settings: from the main user interface, push up on the DualShock 4 to reach the top-level of the system’s menu, and select the toolbox labelled ‘Settings’.
Enter the System submenu: When the long list of options appears, scroll down to the icon named ‘System’ and select it. Turn off HDCP encryption: You’ll find another long list in Settings. Scroll down to ‘Enable HDCP’ and ensure that the box to the right of the label is not ticked.
It will be enabled by default, so simply click on it to disable the irritating feature. If you have any applications open, the system will ask you to close them, so make sure that you’ve saved your game before completing this last step.How to turn off HDCP on an Xbox One. The following is from the Xbox support siteProblem: Playing premium content on your console establishes an HDCP connection with your television. Sometimes the audio sampling rate of the microphone is not matched to the audio recording from the HD PVR 2. In order to match them up, set the sampling rate of the microphone to 48Khz. Here's how to do this:.
On your PC, go to the speaker icon on the right side of your desktop's toolbar, right-click the speaker icon and select 'Recording devices'. Then in the new window that opens, locate your microphone and the right-click it in the list and select the option 'Properties'. A new window called 'Microphone Properties' will open. Go to the 'Advanced' tab. There you'll see a section named 'Default Format', click the drop down menu and select this from the list: 2 channel, 16 bit, 48000 Hz (DVD Quality). Then click apply, restart your PC and give the recording another try.Can I record composite video or S-Video? To record composite video with the HD PVR 2 or Colossus 2, simply connect the yellow connector from your video source to the blue connector on the Hauppauge AV cable.
Then, in Hauppauge Capture, set the Video Source to Composite.For S-Video, you will need to use the optional Hauppauge AV cable model 6021252 which you get purchase on the. Hauppauge Capture has a setting for S-Video.Recordings from composite or S-Video are still made in the H.264 format.
I'm trying to record from a Nintendo Switch, but I'm getting a 'No HDMI signal detected' message. How can I fix this? Some users have reported that they get audio in their HD PVR 2 recordings, but do not hear audio on their monitor. We find that this is caused by the Hauppauge HD PVR 2 being able to accept AC-3 audio but the monitor is only two channel audio.In Hauppauge Capture, go to the Advanced Settings - Audio Encode and click the button which says 'Disable HDMI AC3 support'. This forces your video source to output 2 channel audio which should work with your monitor. Then power cycle all your devices: your game console or video source, your monitor and the HD PVR 2. When you power everything up again, the HD PVR 2 will report that it can only do 2 channel audio and you should now have audio from your monitor.
Can I connect the HD PVR 2 passthrough cable to a standard TV which does not have HDMI? Hauppauge Capture uses any webcam, either HD or standard definition, as long as it has a 'raw' YUV or YUY2 mode. MJPEG and other compressed formats are not used.
Your webcam can be 4:3 or 16:9. Popular webcams include the Microsoft Lifecam HD-3000 plus, if you have a laptop, the built-in webcam.Hauppauge Capture chooses the most suitable video mode supported by your webcam.
You can set the size of the video, and the format (4:3 or 16:9) in the Settings menu of Hauppauge Capture. System Requirements.
Windows 10, 8, 7, Vista and Windows XP with service pack 3. Mac support from HDPVRCapture.comYou can record HD PVR 2 video on pretty much any PC. Older, slow, laptop or desktop PCs can be used to record HD PVR 2 video. Preview video on older PCs and laptops might be jerky and laggy but your recordings will be fine.But when you playback an HD PVR 2 recording on your PC screen, you need a fast CPU and at least 256MB of graphics memory. Here is what we recommend for video playback (minimum):. Dual core CPU 2.0Ghz or faster. Graphics with 256MB memory (or greater).
Sound card. USB 2.0 PortCan I record video from my old Nintendo, PS2 or Wii? Connect the yellow cable from your console (Nintendo, PS2, Wii or any other game console which has a yellow composite video connector) to the Blue connector on the Hauppauge AV cable.
Then connect the red and white audio cables from your Wii to the red and white connectors on the Hauppauge AV cable. Then, in Hauppauge Capture or Hauppauge Capture, select Composite under Video input and Line In under Audio input.Here is a video which shows you how to use the HD PVR 2 with an Nintendo 64: Would you like to support the HD PVR 2 in your own Windows application? If your satellite or cable box or DVR has Component Video connections on the back of the receiver (normally Red/Green/Blue or marked YPrPb), then the answer is 'yes'.By connecting the Component video output from your high definition cable TV or satellite TV set top box to the Component video inputs of the HD PVR 2, you will be able to record the TV programs coming from your set top box to the hard disk. Component video connections are normally the Red/Green/Blue connectors on the back of a set top box. Sometimes they are also called YPrPb or YCrCb connectors.The HD PVR 2 goes between the cable or satellite box and the TV set.
HD PVR 2 has component video in and HDMI out, so the connection to your cable or satellite box can be Component video, and the connection to your TV set is HDMI.Note: the HD PVR 2 also has HDMI in, but from experience we find many cable and satellite boxes put HDCP copy protection on HDMI. What type of recordings can I make with the HD PVR 2? HD PVR 2 encodes in an H.264 format. It records in TS or M2TS file formats, which is a basic H.264 'transport stream'.
Many people would like to know if the quality of a TS or M2TS recording is as good as an MP4 recording. The video quality of MP4 and TS files are the same. The primary difference between TS and MP4 files is that TS files are flat while MP4 files have an index at the beginning of the MP4 file. Otherwise, the video bits inside the files are the same and therefore the video quality of TS, M2TS and MP4 files are the same.All record file types can be used to burn AVCHD Blu-ray compatible discs but you will need to supply your own disc burning application. What type of audio encoding is made with the HD PVR 2? There are two ways of bringing audio into HD PVR 2: through the Line In (RCA) stereo audio jacks on the A/V connector or through the HDMI connector.
Dvr 404 Software Free
When bringing audio in through the stereo jacks, audio is recorded as MPEG 1 layer 2 audio. When bringing audio in through the HDMI connector, the audio is also recorded in the MPEG 1 layer 2 format.DTS audio is currently not supported.If you have the HD PVR 2 model 1512 or the HD PVR 2 Gaming Edition Plus and are bringing in 5.1 channel audio from either HDMI or optical audio, your recordings will be made with 5.1 channel AC-3 audio. Can I output files I've recorded with my HD PVR 2 or other content from my PC back to an external TV monitor through the HDMI outputs on the HD PVR 2? No, the HD PVR 2 itself does not have the ability to play back recorded videos to an external monitor. To playback recorded videos, you will need to connect your laptop or PC to your TV set.The HDMI video output on HD PVR 2 acts as a pass through for live video streaming from your video source through the HD PVR 2 back to your TV monitor. The power of the HD PVR must remain in the on position in order to pass the video through to the external TV. If I record my game play, can I uploaded it to YouTube?
This happens if you connected your PS3 using HDMI and now want to use Component video so you can record with HD PVR 2.To fix, you need to reset the video settings on your PS3. To do this:- Make sure you have the HDMI cable disconnected on your PS3- Then push the PS3 power button on the front of the PS3. You should see the light go Red. This means your PS3 is turned off.- Then hold down the PS3's power button until you hear two beeps (one beep, then about 5 seconds and a second beep).Your PS3 should now be set to Component video out and you should see video in the preview window in Hauppauge Capture.
How To Record Xbox 360 Game & Party Chat. Go to the Xbox Guide Menu.
2. Go along to settings. 3. Select Voice.
4. Go down to voice output and select 'Play though both'. This will make the audio play out your TV and through your mic at the same time.Depending on what game you are on, I highly recommend you turn down game volume as well as sometimes voice chat can't be heard because the game volume is too loud. However I guarantee that there will be a way to turn down your audio setting on whatever game you are on.
Make sure you make it loud enough to hear, but quiet enough to make the voice chat clear and easy to hear. I'm using a PS3, and the video in the Hauppauge Capture preview window has incorrect colors? If you are running an AMD graphics card in the PC which the HD PVR 2 is connected to, you may experience a slight change in brightness every few seconds while in the preview or edit screens. This is due to an issue with hardware acceleration that we have seen in some AMD drivers. This shift does not affect recordings and typically can be eliminated by either changing drivers for the graphics card or by disabling Hardware acceleration.
March Administrator Console Software
Video is jerky or broken up while capturing, yet my recordings are perfect. This is caused by either a slow processor in your laptop or desktop PC, or the display adapter is having a problem. Make sure your video card meets the minimum requirements.
Also try updating to the latest drivers supplied by the manufacturer.In September 2012, there was a problem with the ATI graphics driver which would cause jerky video or freezing of the video screen. This should be fixed with an update from ATI on their graphics drivers.I get a black screen in the preview window when using Component video from a cable TV set top box. Here's a tip from an HD PVR 2 user:'With the Xbox One, to record game commentary I do this:in Kinect settings, use the Kinect mic which forces the party chat to come out of the TV speakers.The Hauppauge game recorder will then pick up the party chat when recording game audio.In order to record your voice (which won't come through the speakers and be picked up), you need to have a Mic plugged in to yourPC and place near your face as you do. Then make sure in Hauppauge Capture you select the mic in the drop down menu and set level.Then you will get the game chat and the game audio recorded, and you speak to your party via Kinect microphone.Basically, one mic to chat with your party and one mic to record your game commentary.'
Dvr 404 Software Reviews
How can I restart Device Central? Troubleshooting What do the lights on front of HD PVR 2 mean?
What do the lights on the HD PVR 2 mean? Click to see the video. Blue light: When HD PVR 2 is powered on and the Windows driver is running, the blue light is on solid. When the blue light is blinking, the HD PVR 2 is not 'seen' by your PC. Check the USB cable!.
Yellow light blinks once when Hauppauge Capture runs and means the HD PVR 2 detects video on the selected Video Input source. If the Yellow light blinks once and then turns to Blue, it means that Hauppauge Capture cannot detect a video signal. There are several reasons this can happen:.
You did not plug in a video cable, or you have the wrong video source selected in Hauppauge Capture. In the Capture tab, make sure Video input is set correctly: HDMI or Component video. And check your video cable and your cable connections! If you have a bad cable or have made a mistake plugging in the cables, you will see a Blue light. If you are recording from an Xbox 360, make sure your video mode is set to either 1080p or 720p.
If you are recording from a PC game system, make sure you have set your PC graphics video mode to 1080p at 60Hz. Green or Blue LED ring: indicates that HD PVR 2 is recording video. Red light: this means the video encoder inside HD PVR 2 cannot send data to your PC. There are a number of reasons this could happen. If your PC is running slowly and cannot get data from HD PVR 2 quickly enough, the red light might go on for a few seconds until the PC can accept data. If there is a problem with your USB cable or the USB port on your PC, the red light might be illuminated.
Change to another USB port on your PC, then power down HD PVR 2, wait a few seconds and power up again. If you continue to see the Red light while recording, check your cabling and if you continue to have problems, contact Hauppauge technical support.' Device is not available' error messageIf you are using Windows 10, make sure you have downloaded and installed the latest version of.
A recent Windows 10 update changed Privacy settings and requires the latest Hauppauge Capture to fix this message.If you are using Hauppauge Capture, this error is normally caused if you did not fully install Hauppauge Capture or something such as anti-virus software prevented Hauppauge Capture from installing. Please go to the and follow the installation instructions once more.Note: make sure you remove the power plug on the HD PVR 2 for a few seconds after installing a new version of Hauppauge Capture. This resets the HD PVR 2 and gets it ready for the new application. Black screen in the Capture preview window and no video on your TV set:. First, make sure, in the Capture tab: if you are using an Xbox, make sure your Xbox is set to 720p or 1080p. Some other Xbox video formats will give a black screen in Capture and your TV set.
If you still do not see video on your TV set or on your PC screen, if you are using a PS3 you might need to reset the video mode on your PS3. To do this on the PS3 Slim, push the power button on the front until the light goes red. Then push and HOLD the button until you hear two beeps.
